| Technical Parameter | Specification Details |
|---|---|
| NOSE TAPER | BT30 |
| LOCATING DIAMETER | 100H6 |
| TOTAL LENGTH | 332 mm |
| FLANGE DIAMETER | 140 mm |
| MAX SPEED | 8000 RPM |
| LUBRICATION | Grease Packed |
| BEARING CONFIGURATION | frontBearing: 7010 P4 | rearBearing: 7008 P4 | arrangement: 2+2 | grade: P4 Precision |
| MECHANICAL | weight: approx 18 kg | orientation: Vertical | housingMaterial: Hardened Alloy Steel |
| Usage Scenario | Target Industry |
|---|---|
| Vertical Machining Centers (VMC) | Automotive Component Machining |
| Toolroom Milling Machines | Aerospace Parts Manufacturing |
| CNC Retrofitting Projects | Die and Mold Making |
| Aluminum and Steel Milling | General Engineering Workshops |
| Precision Prototype Machining | Medical Equipment Production |
This spindle is designed for high-speed performance with a maximum speed capability of 8000 RPM.
The BT30 100mm spindle uses grease-packed lubrication, which makes it virtually maintenance-free and ensures a long service life.
It is equipped with high-precision P4 grade bearings, featuring 7010 P4 at the front and 7008 P4 at the rear in a 2+2 configuration.
The BT30 100MM Milling Spindle is engineered for precision and durability in vertical milling applications. Featuring a high-rigidity cartridge design and a standard BT30 nose taper, it ensures accurate tool holding and exceptional performance. With a max speed of 8000 RPM and P4 grade precision bearings, this spindle is ideal for modern CNC machine builders and VMC retrofitting projects.
bt30 100mm milling spindle price in ahmedabad. high precision bt30 cartridge spindle supplier india. bt30 spindle for vertical milling machine retrofit. buy bt30 belt driven spindle with p4 bearings. best milling spindle manufacturer in gujarat
This CNC Spindle Motor is preferred for Standard BT30 nose taper for precision accuracy, Equipped with P4 grade high-precision bearings, Low maintenance with grease-packed lubrication, Compact 332mm length for easy machine integration, Trusted Indian manufacturer with export quality standards.
Share your requirements, and we’ll provide a tailored quote.
